Product Details:
|
| Model NO.: | LM-20F | Laser Wavelength: | CO2 Laser |
|---|---|---|---|
| Laser Classification: | CO2 | Type: | CO2 Laser Marking Machine |
| Marking Method: | Scanning Marking | Transport Package: | Wooden Box, Wooden Pallet |
| Specification: | 150mm*150mm/200mm*200mm | Trademark: | RuiYi |
| Origin: | China | HS Code: | 8456110090 |
| Production Capacity: | 1000 Pieces Per Month |
| Type | LM-20F |
| Power | 20W/30W/50W |
| Laser Brand | Maxphotonics (Raycus/IPG Optional) |
| Marking Area | 150mm*150mm/200mm*200mm |
| Optional Marking Area | 150mm*150mm/200mm*200mm |
| Marking Depth | ≤1.2mm |
| Marking Speed | 7000mm/s |
| Minimum Line Width | 0.012mm |
| Minimum Character | 0.15mm |
| Repeated Precision | ±0.003mm |
| Life-span of Fiber Laser Module | 100 000hours |
| Beam Quality | M2 <1.5 |
| Focus Spot Diameter | <0.01mm |
| Output Power of Laser | 10%~100% continuously to be adjusted |
| System Operation Environment | Windows XP / W7--32/64bits / W8--32/64bits |
| Cooling Mode | Air cooling--Built-in |
| Temperature of Operation Environment | 15ºC~35ºC |
| Power Input | 220V / 50HZ / single phase or 110V / 60HZ / single phase |
| Power Requirement | <400W |
| Communication Interface | USB |
| Package Dimension | 720mm x 460mm x 660mm |
| Gross weight | 58KG |
| Optional (Not free of charge) | Rotary Device, Moving Table, other customized Automation |
1. desktop design, compact size, easy to move.
2. mechanical structure using aluminum alloy, light weight, good heat dissipation.
3. The optical path is fully enclosed, maintenance-free, and ultra-long life, up to 100,000 hours or more.
4. Stable laser power output, fast marking speed, 2-3 times faster than traditional models.
5. no noise, no consumables, power consumption is 5%-10% of the traditional model.
